SPECIFICATIONS
Specifications are subject to change without notice.
2164
CAPACITIES
Fuel Tank ..............................................................................
Crankcase (approximately) ...................................................
Transmission Case (approximately) ......................................
2-1/8 gallons
3 pints 8 oz.
6 quarts
HYDROSTATIC DRIVE
Speed: Forward .....................................................................
Reverse ....................................................................
0 to 6 mph
0 to 3 mph
ENGINE
Make and Model ...................................................................
Horsepower ...........................................................................
Cylinders ...............................................................................
Bore ......................................................................................
Stroke ....................................................................................
Displacement (cubic inches) .................................................
Engine Speed (governed)
Low Speed .........................................................................
High Speed
(no load) .........................................................................
(full load) .........................................................................
Valve Clearance (engine cold)
Intake .................................................................................
Exhaust ..............................................................................
Ignition ..................................................................................
Spark Plug Gap (Cub Cadet No. 759-3336) .........................
B & S Vanguard
16.0 HP
2
2.68 in.
2.60 in.
29.3
1200 RPM
3600 RPM
3350 RPM
.004-.006 in.
.004-.006 in.
Battery
.030 in.
ELECTRICAL SYSTEM
System Voltage .....................................................................
Battery ...................................................................................
Alternator ..............................................................................
Fuse (auto type
) ....................................................................
Head Lamp Bulb ...................................................................
12 volt neg. ground
725-1706
15 amp regulated
25 amp
725-0963
BRAKES .................................................................................. Internal expanding
TIRE SIZES
Front ......................................................................................
Rear ......................................................................................
15 x 6-6
20 x 9-8
DIMENSIONS
Tread:
Front with 15 x 6-6 tires .....................................................
Rear with 20 x 9-8 tires ......................................................
Wheelbase ............................................................................
Length, over all .....................................................................
Width, over all (w/ mower deck - chute up) ............................
Height, over all (to top of steering wheel) ..............................
Ground Clearance .................................................................
Turning Radius ......................................................................
30.00 in.
27.50 in.
47.00 in.
72.00 in.
51.00 in.
42.00 in.
6.00 in.
26.50 in.
