24
.
OIL CHART
Apply a few drops of SAE engine oil, grease, or use a spray lubricant. Apply
the oil to both sides of pivot points. Wipe off any excess. Start engine and
operate mower briefly to insure that oil spreads evenly.
Number of Oil Points Description
DAILY
4
4
2
2
2
2
1
2
WEEKLY
1
2
2
2
2
Deck Suspension Pivots
Height Adjustment Turnbuckle Clevis Pin
Height Adjustment Handle Pivots
Height Adjustment Stop Pivots
Deck Lift Linkage Pivots
Transport Handle Pivots
Transport Handle Pin
Deck Frame Up-and-Down Pivots
Seat Hinge
Steering Lever Linkage Rod End Bearings
Lever Return Assembly Rod End Bearings
Pump Control Lever Pivots
Grass Collection System Lid Hinges
(If Mower is so equipped)
LUBRICATION CHART
Use a grease-gun filled with NO. 2 Multipurpose Lithium Base Grease
No. of Grease Fittings Description
EVERY 25 HOURS
3
WEEKLY
2
2
2
Blade Spindle Bearings
Front Caster Wheels
Front Caster Wheel Spindles
Mower Deck Ball Wheels
No. of Grease Points Description
Weekly
4
2
Mowing Deck Pivots
Deck Take-Up Idler Pivots
Engine oil: Rimula 15W40 recommended or 10W40 engine oil rated SJ or higher.
Hydrostatic Fluid: Rimula 15W40 recommended. To fill the expansion tank to proper level, about 1” above
the tank bottom where “cold”. If the filter and fluid are removed, a new filter should be used and the transaxle
filled via the expansion tank with Rimula 15W40.
Spindle Lubricant: Use only Shell Alvania RL 2 grease. This grease is an amber-colored grease designed for
high speed bearing applications. It has a base oil viscosity that reduces running losses, has been formulated
for low noise, has excellent corrosion protection, and has excellent bearing lubrication.
General Purpose Lubrication: Use any NLGI grade 2 multi-purpose grease. Shell Albida EP2 is recom-
mended. Shell Albida EP 2 is a red-colored multi-purpose grease designed for heavy-duty bearing applica-
tions. It has high base oil viscosity for mechanical stability, has been formulated for high load, low-speed
applications, and has excellent lubrication and corrosion protection
