11
rain or in slippery conditions. However,
use care when engaging the diff. lock
on manicured turf where sharp turns
are required. Damage to the turf could
occur.
Depressing the brake pedal also actu-
ates the diff. lock pedal. Make certain
the diff. lock disengages when the
brake pedal is released.
Deck Front Lift Rod Assembly
For shipping purposes, the deck front
lift rod assembly has been installed on
the tractor. Cut the tie strap holding
the lift rod assembly to the tractor;
then pull downward on the quick latch
rod at the front of the tractor to remove
the lift rod assembly.
Figure 10
Quick Latch Rod
Lift Rod Assembly
Indicator Light Pod
Figure 11
A
B
C
D
E
A
B
C
D
E
Oil Pressure Indicator
Low Fuel Indicator
Hour Meter
Not Used
Not Used
Hour Meter
The hour meter is part of the indicator
light pod in the dash panel. The hour
meter operates whenever the ignition
switch is in the “ON” or “ON/LIGHTS”
position. Record the actual hours of trac-
tor operation to ensure all maintenance
procedures are completed according to
the schedule in this manual.
Oil Pressure Indicator
WARNING: Operating the
tractor with low oil level or
low pressure could result in
severe engine damage.
The oil pressure indicator is part of the
indicator light pod on the dash panel.
This indicator will illuminate when the
engine oil pressure is low. If this
indicator illuminates, stop the tractor
immediately and check the engine oil
level. If the oil level is within the
operating range, and the light remains
on, contact your Cub Cadet dealer.
Low Fuel Indicator
The Low Fuel indicator is part of the
indicator light pod on the dash panel.
This indicator will illuminate when the
tractor is low on fuel. If the gas tank is
full and the light stays on, contact your
Cub Cadet dealer.
