Cub Cadet 528 SWE User Manual

8
3
Setting Up
Your Snow
Thrower
Figure 10
Figure 9
Figure 8
Drift Cutters
Drift cutters should be used when operating the snow
thrower in heavy drift conditions.
• The drift cutters are assembled to the auger housing
inverted. See Figure 8.
• Remove the carriage bolts by unthreading the hex
nuts which secure them, and reinstall the drift cutters
facing forward before operating the snow thrower.
Refer to Figure 9.
• Secure to the auger housing with carriage bolts and
hex nuts previously removed. See Figure 10.

Cub Cadet 528 SWE Specifications

General

Engine Type	4-cycle OHV
Engine Displacement	277cc
Clearing Width	28 inches
Intake Height	21 inches
Auger Diameter	12 inches
Speeds	6 forward / 2 reverse
Stages	Two-stage
Auger Material	Steel
Impeller Diameter	12 inches
Start Type	Recoil
Throw Distance	40 ft
Starter	Electric
Fuel Tank Capacity	5 qt
Skid Shoes	Adjustable
Warranty	3-year limited
Chute Rotation	200°
