9
SPECIFICATIONS
GENERAL INFO.
Controls: Engine ignition and start switch; throttle; choke; left and right
steering levers; electric blade clutch switch; parking brake;
mower deck lift
Parking Brake: Mechanical linkage brake handle to internal drum brakes
Seat: Adjustable seat and armrests. 4" Adjustment (fore-aft)
Frame: 2" Steel structural tube and plate, all welded construction
Instrumentation Hour meter, Tachometer, Maintenance-minder
Front Caster Wheels: 13 x 5.0 - 6
Drive Wheels: 23 x 9.50 - 12
Tire Pressure: 8-10 psi Rear, 20-25 psi front caster
Fuel Tank: Two 5 gallon w/individual shutoff valves
Ground Speed: 0-9.5 + MPH forward. 0-4.5 MPH reverse
Net Weight: 955 lbs w/48" deck, 1035 lbs. w/60" deck
ENGINE INFO.
Engine: 23HP for 48” & 25HPKohler for 60”
Type: Vertical crankshaft air cooled V-Twin
Air Cleaner: Dual Paper Element with rain cap
Lube System: Pressurized with oil filter
Hydraulic System: In tank filter, 3 quart capacity
Starter: 12-volt electric
Blade Brake Clutch: Electric
TRACTION DRIVE INFO.
Traction Drive: DUP-10 variable-output hydraulic pump connected to individual
wheel motors
CUTTER DECK INFO.
Cutter Deck;Drive: 48", & 60" Belt Driven
Deck Lift: Foot lever w/pin lock for height adjustment
Cutting Height: 1" to 5" in 1/4” increments
No. of Blades 3, belt-driven, power take-off from engine
