Cub Cadet 826 4x4 User Manual

19
Ref.
No.
Part No. Description
1. 05931A Bearing Housing
2. 684-0065 Impeller Assy. 12” dia.
3. 705-5226 Chute Reinforcement
4. 710-0451 Carriage Bolt 5/16-18 x .75” Gr.2
5. 710-0459A Hex Screw 3/8-24 x 1.5” Gr.5
6. 710-0604 Hex Screw 5/16-18
7. 710-0703 Carriage Screw 1/4-20 x .75”
8. 710-0890A Shear Bolt 5/16-18 x 1.5”
9. 712-0116 Jam Nut 3/8-24
10. 712-0324 Hex Lock Nut 1/4-20
11. 712-0429 Hex Lock Nut 5/16-18
12. 712-0798 Hex Nut 3/8-16 Gr.2
13. 712-3010 Hex Nut 5/16-18 Gr.5
14. 712-3068 Hex Patch Nut 5/16-18
15. 715-0114 Spiral Pin
16. 731-1379B Chute Adapter
17. 732-0611 Extension Spring
18. 736-0119 Lock Washer
19. 736-0169 Lock Washer
20. 736-0167 Wave Washer
21. 736-0188 Flat Washer
22. 736-0242 Belleville Washer
23. 736-0463 Flat Washer
25. 738-0281 Shoulder Screw
26. 741-0245 Hex Flange Bearing
27. 741-0309 Flange Ball Bearing
28. 741-0493A Flange Bushing
29. 756-0178 Flat Idler
30. 784-5632A Auger Idler Arm
31. 605-5192A Spiral Assembly: RH 26”
32. 605-5193A Spiral Assembly: LH 26”
33. 618-0415A Gear Assembly: Auger 26”
34. 784-5579A Shave Plate: Auger 26”
35. 710-0451 Carr. Bolt: 5/16-18 x 0.75
36. 712-3010 Hex Nut: 5/16-18 Gr.5
37. 736-0242 Belleville Washer
38. 784-5038B Slide Shoe
39. 684-0040C Auger Housing Assy. 26”
40. 784-5618 Bearing Housing
41. 618-0123 RH Housing
42. 618-0124 LH Housing
43. 710-0642 TT Screw, 1/4-20 x .75
44. 711-0909A Spiral Axle, 26”
45. 714-0161 Hi-Pro Key, 3/16 x 5/8
46. 715-0143 Spring Spiral Pin, .25 x 1.25
47. 717-0528 Worm Gear, 20T
48. 717-0526 Worm Shaft
49. 718-0186 Thrust Collar
50. 721-0325 Grease Plug
51. 721-0327 Grease Seal
52. 736-0351 Flat Washer .76 x 1.5 x .030
53. 736-0369 Flat Washer .508 x 1.0 x .020
54. 736-0445 Flat Washer .76 x 1.5 x .060
55. 741-0662 Flange Bearing .75 x 1.0 x .59
56. 741-0663 Flange Bearing .503 ID x .75 OD
57. 737-3000 Grease Fitting
59. 736-0231 Flat Washer
60. 710-0276 Carriage Screw: Special
Ref.
No.
Part No. Description
Model 826
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Cub Blue: 0685
Powder Black: 0637
