21
Model 826
37. 738-0924 Shoulder Screw
38. 741-0598 Hex Flange Bearing
39. 741-0600 Ball Bearing
40. 741-0701 Flange Bushing
41. 741-1111 Hex Flange Bearing
42. 746-0897 Auger Clutch Cable
43. 746-0898 Drive Clutch Cable
44. 746-0956 Steering Cable
45. 748-0190 Spacer
46. 750-1161A Support Tube: Axle
47. 750-1162 Spacer
48. 756-0625 Roller Cable
49. 784-5590 Shift Bracket
50. 784-5687A Auger Clutch Cable Guide Bracket
51. 784-5689A Front Support Guide Bracket
52. 784-5730A Retaining Shaft RH: Actuator Drive
53. 784-5732 Frame Cover
54. 784-5733 Roller Bracket: Drive Cable
55. 784-5740 Retaining Shaft LH: Actuator Drive
56. 710-1233 Oval C-Sunk Machine Screw
57. 712-0127 Weld Nut
58. 725-0157 Cable Tie (not shown)
59. 746-0950 Turn Trigger
60. 784-5731A Frame
777D03040 Label: Auger Side 4x4
777D03165 Label: Heated Handle
777D04558 Label: Handle Panel
777D04559 Label: Housing 826 4x4
777D04560 Label: Engine
777I20508 Label: H-Steer LH
777I20724 Label: H-Steer RH
777S30511 Label: Chute Danger
777S30514 Label: Housing Danger
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1. 618-0043 Dogg Assembly: RH
2. 618-0044 Dogg Assembly: LH
3. 618-0303A Shift Assembly: Steerable Drive
4. 618-0420A Chain Case Assembly: RH
5. 618-0421A Chain Case Assembly: LH
6. 656-0012A Friction Wheel Disc Assy.
7. 684-0014B Shift Rod Assembly
8. 684-0042C Bearing
9. 684-0130 Transmission Frame Assembly
10. 684-0131A Support Bracket Assembly
11. 710-0599 Hex Washer Screw 1/4-20 x 0.5”
12. 710-0788 Hex Washer Screw 1/4-20 x 1.0”
13. 710-1652 Hex Washer Screw 1/4-20 x .625”
14. 711-1267 Drive Shaft
15. 711-1268 Actuator Shaft
16. 711-1364 Pin
17. 712-0711 Jam Nut 3/8-24 Gr.8
18. 712-3017 Hex Nut: 3/8-16
19. 713-0131 Chain
20. 713-0233 Chain
21. 713-0413 Sprocket: 19T
22. 713-0473 Sprocket
23. 714-0104 Cotter Pin
24. 714-0474 Cotter Pin
25. 716-0102 Snap Ring
27. 732-0209 Extension Spring
28. 732-0264 Extension Spring
29. 736-0105 Bell Washer
30. 736-0142 Flat Washer
31. 736-0160 Flat Washer
32. 736-0169 Lock Washer
33. 736-0351 Flat Washer
34. 736-0626 Flat Washer
