Cub Cadet 826 4x4 User Manual

25
Model 826
Ref.
No.
Part No. Part Description
1. 684-0008A Shift Arm Assembly
2. 710-0262 Carriage Bolt 5/16-18 x 1.5”
3. 710-0449 Carriage Bolt 5/16-18 x 2.25”
4. 710-0788 TT Screw 1/4-20 x 1”
5. 710-0837 C-Sunk Screw #10-16x 0.625”
7. 710-3008 Hex Screw 5/16-18 x .75”
8. 711-0677 Ferrule
9. 712-0429 Hex Lock Nut 5/16-18
10. 712-3010 Hex Nut 5/16-18
11. 714-0104 Cotter Pin
12. 720-0284 Handle Knob
13. 725-1757 Heated Grip
14. 736-0242 Belleville Washer
15. 736-0275 Flat Washer
16. 736-0451 Saddle Washer
17. 747-0620A Shift Rod: Upper
18. 747-0621 Shift Rod: Lower
19. 749-0951 Lower Handle
20. 749-0952A Upper Handle: L Style RH
21. 749-0953A Upper Handle: L Style LH
22. 750-0963 Connector: Shift Rod
23. 618-0419 Gear Assembly: Ring
24. 629-0937 Electric Harness: Lower
25. 710-0262 Carriage Bolt: 5/16-18 x 1.5”
26. 710-0451 Carriage Bolt: 5.16-18 x .750”
27. 710-0599 TT Screw: 1/4-20 x 0.5”
28. 710-0602 TT Screw: 5/16-18 x 1”
29. 710-0805 Hex Screw: 5/16-18 x 1.5”
30. 710-0817 TT Screw: 5/16-18 x 1.25”
31. 710-0896 Hex Screw AB:1/4-14 x 0.625”
32. 710-3008 Hex Screw: 5/16-18 x .75”
35. 712-3027 Hex Flange Lock Nut
36. 724-0249 Electric Motor: Chute Crank
37. 725-0157 Cable Tie
38. 731-0851A Chute Flange Keeper
39. 731-1300A Lower Chute
40. 731-1313C Cable Guide: Chute Tilt
41. 731-1320 Upper Chute
42. 731-2279 Motor Cover: Chute Rotation
43. 736-0159 5/16 Washer
44. 736-0242 Belleville Washer
45. 736-0506 Special Washer
46. 746-0896 Control Cable
47. 746-0901 Control Cable
48. 750-1232 Spacer
49. 782-0599 Motor Bracket
50. 784-5594 Cable Bracket
51. 784-5604 Handle: Chute Tilt
52. 629-0936 Harness Assembly: Upper
53. 684-0036 Handle Assembly RH
54. 684-0037 Handle Assembly LH
55. 710-1003 Special Hex Screw
56. 712-0271 Hex Sems Nut: 1/4-20
57. 712-0693 Hex Nut
58. 716-0398 Lock Ring: Toggle Switch
59. 720-0232 Shift Knob
60. 725-1672 Lamp Housing
61. 725-1755 Toggle Switch: Double Throw
62. 725-1756 Toggle Switch: Single Throw
63. 725-1759 Halogen Lamp: 50W, 12V
64. 726-0152 Mounting Clamp
65. 731-2276 Handle Panel
66. 736-0226 Flat Washer
67. 747-1136 Headlight Retainer
68. 714-0507 Cotter Pin: 3/32 x .75
69. 747-0877 Cam Rod
70. 784-5680 RH Handle Support Bracket
71. 784-5679 LH Handle Support Bracket
72. 748-0362 Cam Handle Lock
73. 748-0363 Handle Lock Pawl
74. 732-0145 Compression Spring: .36 x 1.0
75. 710-0459A Hex Cap Screw: 3/8-24 x 1.5
76. 784-5619A Shift Handle
77. 712-0116 Jam Nut, 3/8-24
78. 732-0193 Comp. Spring: .39 x .6 x .88
79. 736-0105 Bell Washer
80. 784-5682 RH Handle Support Bracket
81. 784-5681 LH Handle Support Bracket
82. 711-0653 Clevis Pin
83. 684-0102 Handle Panel Assembly
Ref.
No.
Part No. Part Description

Cub Cadet 826 4x4 Specifications

General

Brand	Cub Cadet
Model	826 4x4
Category	Snow Blower
Language	English
