19
Seat Adjustment Lever
The seat adjustment lever is located beneath the left
side of the seat. This lever is used to adjust the seat
forward or backward to the desired operating position.
See Figure 19.
Figure 19
Mid PTO Lever
The tractor’s Mid PTO is used power implements
designed to be operated at 2000 RPM.
The mid PTO lever is located in the panel below the
right side of the seat. See Figure 20.
• Turn the PTO switch to the manual position.
• Pull the lever upward to engage the Mid PTO.
• Push the lever down to disengage the Mid PTO.
WARNING: To avoid possible personal
injury or damage to the tractor, make
sure the Mid PTO is disengaged (lever
down) when not in use.
Figure 20
SEAT ADJUSTMENT LEVER
MID PTO
LEVER
Engage
Disengage
