Cub Cadet 945 SWE User Manual

21
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 05244A Housing, Bearing ......................... 2
2 05845C Housing, Double D Bearing ......... 2
3 618-0257 Gear Box Assembly, Auger ......... 1
4 618-0281A Bracket Assembly, Auger Brake .. 1
5 684-0090A Impellar , 16" ............................... 1
6 684-0164A
684-0166A
684-0155A
Housing, Auger — For 28" S.T. ...
Housing, Auger — For 33" S.T. ...
Housing, Auger — For 45" S.T. ...
1
1
1
7 684-04151
684-04151
Spiral Ass’y, LH — 28" & 33" S.T.
Spiral Ass’y, LH — 45" S.T.
2
3
8 684-04152
684-04152
Spiral Ass’y, RH — 28" & 33" S.T.
Spiral Ass’y, RH — 45" S.T.
2
3
9 710-0371 Screw, Hex Cap Lock, .................
5/16-18 x .875 GR5
1
10 710-04527 Screw, Carr, Stnls Stl, 3/8-16 x .75 4
11 710-0451 Screw, Carriage, 5/16-18 x .75 .... 11
12 710-0459A Screw, Hex Cap, 3/8-24 x 1.5 GR5 1
13 710-0528 Screw, Hex Cap, .........................
5/16-18 x 1.25 GR5
1
14 710-0604A Screw, Hex Wash Hd. Tapp ........
5/16-18 x .625
6
15 710-1260A Screw, Hex Wash Hd Tapp .........
5/16-18 x .75
3
16 710-3008 Screw, Hex Cap, 5/16-18 x .75 GR5 2
17 710-04526 Screw, Carr, Stnls Stll 3/8-16 x 1.0 2
18 711-0640 Stud, 3/8-16 x 2.68 ...................... 5
19 711-0677 Ferrule ......................................... 1
20 712-0116 Nut, Hex Insert Jam Lock, ...........
3/8-24 GR5
1
21 712-04063 Nut, Hx Ins Flnge Lk, 5/16-18 GrF 18
22 712-0717 Nut, Insert, 3/8-16 ....................... 1
23 712-04102 Nut, Hex, Stnls Stl, 3/8-16 ........... 6
24 714-0104 Pin, Internal Cotter ...................... 1
25 714-0126 Key, Hi Pro, 3/16 x 3/4 ................ 1
26 714-0135 Key, Woodruff, #91: 1/4 x 3/4 ...... 1
27 714-04040
714-04040
Pin, Bowtie Cotter — 28" & 33" S.T.
Pin, Bowtie Cotter — 45" S.T.
4
6
28 715-0118 Pin, Spirol, 5/16 x 1.75 ................ 2
29 725-0157 Tie, Cable .................................... 1
30 731-1696A Adapter, Chute, 6" ....................... 1
31 731-05162 Spacer, 1.0 x 1.5 x 2.5Lg — 33" S.T. 2
32 731-05163
731-05163
Spacer, 1.0 x 1.5 x 1.0Lg — 28" &
33" S.T.
Spacer, 1.0 x 1.5 x 1.0 — 45" S.T.
4
12
33 731-2635 Clip, Mounting ............................. 1
34 731-2643 Tool, Cleanout ............................. 1
35 732-0858 Spring, Extension ....................... 1
36 736-0169 Washer, Lock, 3/8 ....................... 5
37 736-0174 Washer, Wave, .625 x .885 x .015 2
38 736-0242 Washer, Belleville, .34 x .872 x .06 10
39 750-04020 Spacer, 1.004 x 1.375 x .25 ........ 2
40 736-0271 Washer, Spring, .317 x .625 x .02 1
41 736-3008 Washer, Flat, .344 x .75 x .12 ..... 1
42 736-3046A Washer, Flat, Hdn., 1.01 x 1.86 x .06 2
43 738-0281 Screw, Shoulder, .625 x .17:3/8-16 2
44 738-04155
738-04155
Pin, Shear, .25 x 1.75 — 28" & 33"
S.T.
Pin, Shear, .25 x 1.75 — 45" S.T.
4
6
45 738-04156
738-04158
738-04159
Shaft, Spiral, — 28" S.T. .............
Shaft, Spiral, — 33" S.T. .............
Shaft, Spiral, — 45" S.T. .............
1
1
1
46 741-0192 Bearing, Flange w/Flats .............. 2
47 741-04024 Bearing, Self Aligning ................. 1
48 741-0475 Bushing, Nylon ........................... 1
49 741-0494
741-0494
Bushing, Flange, — 28" & 33" S.T.
Bushing, Flange, — 45" S.T. ......
8
12
50 747-0980 Rod, Auger Idler ......................... 1
51 749-1117 Tube, Support ............................. 2
52 754-0222A Belt, V, 1/2 x 44 .......................... 1
53 756-0178 Pulley, Flat Idler, 2.75 OD .......... 1
54 756-0243 Pulley, Auger Drive, 10.0 ............ 1
55 784-0385A Bracket, Auger Idler .................... 1
56 784-5076 Bracket, Gear Box Support ......... 1
57 784-5123 Bracket, Chute Crank ................. 1
58 784-5710 Plate, Support ............................. 1
59 784-5711 Bracket, Chute ............................ 1
60 790-00197
790-00196
790-00195
Plate, Shave, Stnls Stl — 28" S.T.
Plate, Shave, Stnls Stl — 33" S.T.
Plate, Shave, Stnls Stl — 45" S.T.
1
1
1
61 790-00181 Blade, Guide ............................... 2
62 790-00199 Shoe, Skid, Stnls Stl ................... 2
63 710-04525 Screw, Carr., Stls Stl,5/16-18 x .75
— 28" & 33" S.T. .....................
— 45" S.T. ...............................
5
7
64 712-04103 Nut, Hex, Stnls Stl,
— 28" & 33" S.T. .....................
— 45" S.T. ...............................
5
7
65 736-04216 Washer, Bell, .34x.87x.06, Stnls Stl,
— 28" & 33" S.T. .....................
— 45" S.T. ...............................
5
7
66 736-04215 Washer, Bell, .37x.87x.06, Stnls Stl 6
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code to the part number to
order a replacement part. For instance, if a
part, numbered 700-xxxx, is painted Cub
Yellow, the part number to order would be
700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
