23
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 05244A Housing, Bearing ......................... 4
2 618-0279 Dogg, Steering Drive, LH ............ 1
3 618-0280 Dogg, Steering Drive, RH ............ 1
4 618-0282D Shaft Assembly, Steering ............ 1
5 618-04178
718-04034
710-1652
Assembly, Friction Wheel ............
Wheel, Friction .........................
Screw, Hex Wash Hd Tapp ......
1
1
4
6 684-0118 Bracket, Auger Actuator .............. 1
7 684-0119 Bracket, Drive Actuator ............... 1
8 684-0122 Sprocket, 32T .............................. 2
9 684-0161 Arm, Shift .................................... 1
10 684-0162 Bracket, Friction Drive Support ... 1
11 684-04103 Rod Assembly, Shift .................... 1
12 710-0195 Screw, Hex Cap, 1/4-28 x .625 GR5 2
13 710-0538 Screw, Hex Cap Lock, .................
5/16-18 x .625 GR5
8
14 710-0599 Screw, Hex Wash. Hd. Tapp .......
1/4-20 x .5
2
15 710-0604A Screw, Hex Wash. Hd. Tapp .......
5/16-18 x .625
6
16 710-0788 Screw, Hex Wash. Hd. Tapp .......
1/4-20 x 1.0
1
17 710-1652 Screw, Hex Wash. Hd. Tapp .......
1/4-20 x .625
14
18 710-1879 Screw, Hex Patch Lock, ..............
3/8-16 x .88 GR5
2
19 710-3001 Screw, Hex Cap, 3/8-16 x .88 GR5 4
20 710-3008 Screw, Hex Cap, 5/16-18 x .75 GR5 3
21 710-3103 Screw, Hex Cap, 5/16-18 x 2.0 GR5 2
22 710-3180 Screw, Hx Cap, 5/16-18 x 1.75 GR5 2
23 711-04279 Shaft, Hex Drive .......................... 1
24 711-1193 Shaft, Actuator ............................ 1
25 711-1194 Shaft, Steering Actuator .............. 1
26 712-0116 Nut, Hex Insert Jam Lock, ...........
3/8-24 GR5
2
27 712-0138 Nut, Hex, 1/4-28 GR5 .................. 3
28 712-04063 Nut, Hx Flnge Insert Lk, 5/16-18 GrF 4
29 712-04065 Nut, Hx Flnge Insert Lk, 3/8-16 GrF 2
30 712-0413 Nut, Hx Insert Jam Lk, 5/8-18 GR5 1
31 712-3010 Nut, Hex, 5/16-18 GR5 ................ 9
32 712-3017 Nut, Hex, 3/8-16 GR5 .................. 4
33 713-0284 Chain, Endless, #41 x 36L .......... 1
34 713-0286 Chain, #420 x 40L ....................... 2
35 713-04015 Sprocket, #41 x 10T .................... 1
36 714-0101 Pin, Internal Cotter ...................... 4
37 714-0104 Pin, Internal Cotter ...................... 1
38 714-0115 Pin, Cotter, 1/8 x 1.0 ................... 2
39 714-0388 Key, Hi-Pro, 3/16 x 5/8 ................ 1
40 716-0136 Ring, Retaining ............................ 1
41 717-0302 Plate, Drive ................................. 1
42 732-0121 Spring, Extension ....................... 1
43 732-0209 Spring, Extension ....................... 2
44 736-0119 Washer, Lock, 5/16 ..................... 9
45 736-0158 Washer, Lock, 5/8 ....................... 1
46 736-0160 Washer, Flat, .53 x .93 x .05 ....... 4
47 736-0163 Washer, Flat, Hdn, 1.03 x 1.62 x .03 2
48 736-0217 Washer, Lock, 3/8 ....................... 6
49 736-0242 Washer, Belleville, .34 x .872 x .06 2
50 736-0300 Washer, Flat, .406 x .875 x .059 . 2
51 736-0329 Washer, Lock, 1/4 ....................... 3
52 736-0623 Washer, Flat, .64 x 1.24 x .06 ..... 2
53 737-3000 Fitting, Lube, 3/16 Drive ............. 1
54 738-0143 Screw, Shoulder, .498 x .34:3/8-16 2
55 738-0279 Spindle, Drive Plate .................... 1
56 738-0924 Screw, Hex Shoulder, 1/4-28:.375 1
57 741-0163A Assembly, Bearing/Housing ....... 2
58 741-0225 Bearing, Hex Flange ................... 2
59 741-04025 Bearing, Self Aligning ................. 2
60 741-04076 Bearing, Ball ............................... 2
61 741-0563 Bearing, Ball ............................... 4
62 741-0748 Bushing, Flange, .5 ID x .627 OD 1
63 746-0949A Cable, Steering ........................... 2
64 746-0951 Cable, Auger Idler ....................... 1
65 747-0973 Rod, Drive Clutch ....................... 1
66 750-0903 Spacer, Split, .514 x .632 x 2.44 . 2
67 750-0997 Spacer, .675 x 1.0 x .23 .............. 1
68 750-1302A Spacer, .6725 x 1.125 x 2.485 .... 1
69 756-0344 Pulley, Drive ............................... 1
70 756-0625 Roller, Cable ............................... 1
71 784-0379 Cover, Upper Frame ................... 1
72 784-0380 Cover, Lower Frame ................... 1
73 784-0384 Bracket, Auger Cable Guide ....... 1
74 784-0403 Bracket, Shift Shaft ..................... 1
75 784-0406 Bracket, Frame Support ............. 1
76 784-0407 Bracket, Axle Support ................. 1
77 784-04170 Frame, Transmission ..................
Includes 712-0717 Insert Nuts
1
78 738-1165A
738-1164A
738-1166A
Axle, Wheel — 28" S.T. ..............
Axle, Wheel — 33" S.T. ..............
Axle, Wheel — 45" S.T. ..............
1
1
1
79 714-0151A Pin, Klik ....................................... 2
80 710-3103 Screw, Hex Cap, — 45" S.T. ONLY
5/16-18 x 2.0 GR5
2
81 712-04063 Nut, Hx Flnge Insert Lk, — 45" S.T.
ONLY — 5/16-18 GrF
2
82 See Wheel Table Below
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
WHEEL TABLE
S. T. Model Description Wheel Ass’y Tire Rim Valve Bearing
28" S.T. — 928 SWE 16 x 4.80 x 8 X-Trac — LH 634-04179 734-2038 734-1532
734-0255 741-0246A
16 x 4.80 x 8 X-Trac — RH 634-04180
33" S.T. — 933 SWE 16 x 6.50 x 8 X-Trac — LH 634-0225
734-2031 734-1124
16 x 6.50 x 8 X-Trac — RH 634-0226
45" S.T. — 945 SWE (2) 16 x 6.50 x 8 X-Trac — LH (2) 634-0225
(2) 16 x 6.50 x 8 X-Trac — RH (2) 634-0226
