21
Ref.
No.
Part No. Description
1. 647-00408 Control Handle
2. 731-0904A Upper Control Handle
3. 16864 6 Spd. Rack Cable Bracket
4. 731-0620 Control Lever
5. 713-0397 Gear Insert
6. 732-0627 Shift Lever Spring
7. 731-0924 6 Speed Shift Lever
8. 731-0905A Lower Control Housing
9. 710-1667A C Sunk Tap Screw #10 x .75 Lg
10. 731-0906 Cable Mounting Cap
11. 746-0711A Drive Cable 51.0
12. 712-0324 Top Lock Nut 1/4-20
13. 746-0883 Control Housing
14. 710-1270 Oval C-Sunk Screw
15. 746-1131 Control Cable 46”
16. 749-0439D Upper Handle
17. 720-0284 Wing Nut
18. 736-0451 Saddle Washer .320 ID x .830 OD
19. 710-1174 Carriage Bolt 5/16-18 x 2.0
20. 726-0240 Cable Tie
21. 749-0907B Lower Handle
27. 731-1901 Trail Shield
28. 732-0842 Trail Shield Wire
29. 631-0066 Chute Assembly
30. 731-1832 Side-Discharge Chute
31. 731-1833 Mulch Cover
32. 782-0078B Deck 21”
33. 712-0397 Wing Nut
34. 710-0703 Carriage Bolt 1/4-20 x .75
35. 746-0939 6 Speed Cable
36. 782-7574A Cable Adjustment Bracket
37. 736-0270 Bell Washer .265 ID x .75 OD
38. 712-0287 Hex Nut 1/4-20
39. 710-0167 Carriage Screw 1/4-20 x .50
40. 712-0138 Hex Nut 1/4-28
41. 782-7575A Cable Mounting Bracket
42. 736-0329 Lock Washer 1/4
43. 756-0625 Roller Cable
44. 738-0924 Shoulder Screw .375 ID x 1/4-14
45. 736-0264 Flat Washer .330 ID x .630 OD
46. 714-0104 Cotter Pin
47. 732-0306 Compresion Spring
48. 734-1981A Wheel 9 x 2
49. 712-0414 Top Lock Tab Weld Nut 1/4-20
50. 16855 Ratchet Pawl Plate
51. 10622B Plastic Spring Ratchet
52. 748-0381 Pawl RH
748-0188B Pawl LH
53. 738-0137A Shld Screw .340 ID x .285 OD
54. 748-0318 Wheel Rachet
55. 736-0270 Bell Washer .265 ID x .75 OD
56. 710-0751 Hex Cap Screw 1/4-20 x .620
57. 737-3000 Grease Fitting
58. 736-0931 Flat Washer .203 ID x .403 OD
59. 747-0924 Wheel Pin Lock
60. 682-9020A Caster Assembly RH
682-9021A Caster Assembly LH
61. 682-9024 Caster Bracket Assembly RH
682-9026 Caster Bracket Assembly RH
62. 710-1348 Screw 1/4-14 x .500
63. 710-0896 Screw 1/4-14 x .625
64. 710-0654A Hex Washer Screw 3/8-16 x 1.0
65. 711-1146 Caster Axle
66. 736-0204 Flat Washer .344 ID x .62 OD
67. 710-0703 Carriage Screw 1/4-20 x .75
68. 710-1242 Torx Screw
69. 736-0232 Wave Washer .531 ID x .781 OD
70. 712-0397 Wing Nut
71. 710-0260 Carriage Bolt 5/16-18 x .62
72. 754-0460 Belt 3/8 x 39.24
73. 656-0613 Pulley Assembly
74. 750-1071 Sleeve Spacer .88 ID x 1.13 OD
75. 750-1070 Sleeve Spacer .88 ID x 1.00 OD
76. 782-7597 Pivot Bracket
77. 710-0654A Screw 3/8-18 x 1.0
78. 782-7596 Control Arm
79. 732-0807 Torsion Spring
80. 711-1114 Pivot Shaft
81. 736-0526 Wave Washer 1.38 ID x .88 OD
82. 731-1828 Baffle
83. 710-0653 Screw 1/4-20 x 3.75
84. 753-0609 Blade Adapter Kit
85. 742-0741 21” Mulching Blade
86. 736-0524A Blade Bell Support
87. 710-1257 Hex Bolt 3/8-24 x 2.5
88. 731-1874 Chute Door
89. 732-0819 Torsion Spring
90. 726-0111 Push Cap
91. 747-0965 Pivot Rod
92. 731-1713B Discharge Chute
94. 726-0214 Push Cap
95. 736-0366 Flat Washer.640 ID x 1.12 OD
96. 741-0685 Flange Bearing
97. 712-3004A Flange Lock Nut 5/16-18
98. 734-1857 Wheel 7 x 2
99. 731-1888 Hubcap - Spoke w/ Hole
100. 731-0982A Hubcap - Radial Spoke
101. 682-3052 Handle Bracket Assembly - RH
682-3053 Handle Bracket Assembly - LH
Ref.
No.
Part No. Description
Model 997
