23
Model 997
Ref.
No.
Part No. Part Description
1. 720-0223 Grip
2. 732-0803A Spring Lever
3. 738-0529 Shoulder Nut .825 x .165 Lg.
4. 710-0751 Cap Screw 1/4-20 x .620
5. 736-0270 Bell Washer .285 ID x .75 OD
6. 748-0318 Wheel Rachet
7. 736-0369 Flat Washer .508 ID x 1.0 OD
8. 782-0566B Pivot Arm Assembly
9. 750-0515 Spacer .510 ID x .70 OD
10. 741-0978 Sleeve Bearing .504 ID x .830 OD
11. 750-1056 Shoulder
12. 710-0653 Tap Screw 1/4-20 x .375
13. 682-7528 Chain Cover Assembly
14. 741-0324 Flange Bearing .506 ID x .590 Lg
15. 682-7526 Transmission Axle Assembly
16. 618-0263A Transmission Assembly
17. 710-0604A Hex Screw 5/16-18
18. 713-0453 Chain
19. 638-0012 Rear Axle Assembly
20. 741-0522 Flange Bearing .506 ID x .715 Lg
21. 732-0832 Torsion Spring
22. 750-0151 Spacer .550 ID x .750 OD
23. 710-1315 Screw 3/8-16 x .25
24. 711-0835 Clevis Pin .50 Dia x 4.82 Lg.
25. 750-0807 Spacer .385 ID x .624 OD
26. 782-0568 Spring Bracket: Height Adjustment
27. 710-1652 Screw 1/4-14 x .825
28. 714-0474 Cotter Pin
29. 712-3025 Hex Jam Nut 5/16-24
30. 736-0425 Bell Washer .325 ID x .930 OD
31. 756-0656 Pulley
32. 736-3084 Flat Washer .510 ID x 1.120 OD
33. 712-0896 Hex Jam Nut 1/4-28
34. 782-7598 Belt Keeper
35. 741-0600 Bearing
36. 732-0849A Extension Spring
37. 750-1050 Flange Spacer
38. 682-0027A Idler Bracket Assembly
39. 710-0299 Hex Cap Screw 1/4-28 x 1.0
40. 741-0682A Bearing Sleeve
41. 736-0570 Flat Washer .885 ID x 1.45 OD
42. 721-0329 Oil Seal
43. 721-0325 Plug
44. 618-0253 Upper Housing Assembly
45. 782-7601A Cable Bracket
46. 741-0690 Bearing
47. 736-0616 Thrust Washer .504 ID x .70 OD
48. 782-7595 Pivot Bracket
49. 741-0324 Flange Bearing
50. 711-1168 Output Shaft 6T
51. 717-1469 Gear 34T
52. 741-0674 Bearing
53. 717-1487 Pinion Shaft 10T
54. 736-0314 Thrust Washer 3/8 x .70
55. 736-0569 Thrust Washer .388 x .625
56. 618-0252 Lower Housing Assembly
57. 710-0642 Hex Screw 1/2-20 x .75
58. 611-0066 Shaft Assembly
59. 664-0180 Grassbag
60. 747-0940A Support Rod w/ Rope Guide
61. 747-0939 Pivot Rod
62. 747-0937 Grassbag Frame
63. 631-0071 Grassbag Cover
Ref.
No.
Part No. Part Description
