37
37
6
6
48
Do NOT fasten rope to any
part of your body or clothing.
5041
DETAIL V
SCALE 1 : 4
48
52
Insert Connecting Tubes (37) into Hitch Mount Tubes (6) and secure with
Quick-Release Pins (48). Install Hitch Pin (11) and secure with Hairpin(12).
Install handle (52) and tie Dump Rope (50) securely around exposed section
of Center Frame Tube(41).
9
Assembly Instructions
13
14
To Next Page
