Unscrew Thumb Screw from Tension Tube Assembly (44). Next, Hold Hopper Bag (38) open
and carefully insert Tension Tube Assembly (44) through opening in Hopper Bag and into hole
in bottom Center Frame Tube (41). Pull top Center Frame Tube over
tension tube and align holes.
Insert thumb screw that came with Tension Tube Assembly (44) through
top Center Frame Tube (41) and screw into top of Tension Tube.
Secure Hopper Bag around Top Frame Tubes with Velcro tabs.
SHOWN INSTALLED
SHOWN INSTALLED
8
Assembly Instructions
