17
ASSEMBLY AND OPERATING
INSTALLING THE POWER CELL
Once the Power Cell has been fully
charged and you are ready to start
trimming, you will have to install the
Power Cell into the trimmer (Fig. 2).
1. Position the Power Cell (1) with the
"TOP" label (2) facing upward.
2. Slide the Power Cell into the
matching cavity (3) in the rear of the
upper cowling (4).
NOTE: Make sure you push the Power
Cell fully into the cavity. The locking
latch (5) will click when the Power Cell is
properly installed.
3. Pull outward on the Power Cell to
verify that it is being held in place by
the locking latch.
To remove the Power Cell for recharging
or storage, press the locking latch
toward the Power Cell. While holding
the locking latch toward the Power Cell,
pull the Power Cell out of the tool.
Fig. 2
1
5
3
4
2
