Periodic Maintenance and Adjustment 8-18
3. If the oil is below the brim of the filler hole,
add sufficient oil of the recommended
type to raise it to the correct level.
CAUTION:
1. Be sure no foreign material enters the
final gear case.
2. Clean the sensor every 300 mi (500 km)
period.
4.
Inst
all the oil filler bolt, and then tighten it
to the specified torque.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
Changing the Final Gear Oil
1.
Place the vehicle on a level surface.
2.
Place a container under the final gear
case to collect the used oil.
3. Remove the oil filler bolt and the drain
bolt to drain the oil.
1. Final gear oil drain bolt
4. Install the drain bolt, and then tighten it to
the specified torque.
T
ightening torque:
Final gear oil drain bolt:
20 Nm (2.0 m·kgf, 14 ft·lbf )
5. Add the recommended final gear oil up
to the brim of the filler hole.
To Next Page
