8-21 Periodic Maintenance and Adjustment
1. Differential gear oil drain bolt
4. Install the differential gear oil drain bolt,
and tighten it to the specified torque.
Tightening torque:
Differential gear oil drain bolt:
9.8Nm (0.98 m·kgf, 7.1 ft·lbf)
5. Fill the differential gear case with the
recommended oil.
Recommended oil:
SAE 80 API GL-5 Hypoid gear oil
Oil quantity:
0.32 L (0.28 lmp qt, 0.34 US qt)
CAUTION:
Be sure no foreign material enters the
differential gear case.
6. Install the differential gear oil filler bolt,
and then tighten it to the specified
torque.
Tightening torque:
Differential gear oil filler bolt:
23Nm (2.3m·kgf, 17 ft·lbf)
7. Check for oil leakage. If oil leakage is
found, check for the cause.
To Next Page
