8-51 Periodic Maintenance and Adjustment
Headlight Beam Adjustment
CAUTION:
It is advisable to have a service center make
this adjustment.
To raise the beam, turn the adjusting screw
in directionⓐ.
To lower the beam, turn the adjusting screw
in directionⓑ.
1. Headlight beam adjusting screw
Tail/Brake Light Bulb Replacement
If a tail/brake light bulb burns out, replace it
as follows:
1. Remove panel A (if replacing the left
tail/brake bulb) or panel B (if replacing
the right tail/brake bulb) by removing the
quick fasteners and bolts.
1. Panel A
To Next Page
