4-28 Control Functions
Auxiliary DC jack
The auxiliary DC jack is located at the right
side of the front panel.
The auxiliary DC jack can be used for
suitable work lights, radios, etc.
The auxiliary DC jack should only be used
when the engine is running.
1. Auxiliary DC jack cap
1. Set the light switch to “OFF”.
2. Start the engine. (See pages 6-1-6-3. )
3. Open the auxiliary DC jack cap, and then
insert the accessory power plug into the
jack.
4. When the auxiliary DC jack is not being
used, cover it with the cap.
1. Auxiliary DC jack
Maximum rated capacity for the auxiliary
DC jack:
DC 12V, 120W (10 A)
