Cub Cadet Challenger Series - Page 215

Electrical
6‐17
Starter Motor
No. Part Name Qty Remarks
1
Removing the starter motor
1
Remove the parts in the order
Starter moto
r
lead listed
2 Starter motor / O-ring 1 / 1
Disassembling the starter motor
1 Bracket 1 1
2 Washe
r
kit 1
3 Bracket 2 1
4 Shims
5 Brush seat 1 / Brush seat 2 1 / 1
6
A
rmature coil 1 1
7 Yoke 1
