Specifications
2-20
ENGINE TIGHTENING TORQUES
Part to be Tightened Part
Name
Thread
Size
Qty Torque
Nm
Torque
Ft
Lbs
Shift arm Bolt 6 mm
1
14 10
Shift rod locknut (select leve
unit) Nut 8mm
1
15 11 LH
Shift rod locknut (shift arm side) Nut 8mm
1
15 11
Select leve
unit Bolt 8mm
3
15 11
Plug (right crankcase) Plug 14 mm
1
18 13
Water pump assembly Bolt 6mm
2
10 7.2
Water pump housing cove
Bolt 6mm
2
12 8.7
Coolant drain bolt Bolt 6mm
1
10 7.2
Coolant inlet
oint Bolt 6mm
2
10 7.2
Coolant outlet
oint Bolt 6mm
2
10 7.2
ir bleed bolt (coolant outlet
oint) Bolt 6mm
1 9
6.5
Coolant reservoi
Bolt 6mm
2 7
5.1
Radiator bracket and frame Bolt 6mm
4 7
5.1
Fuel pump Bolt 6mm
2 7
5.1
Fuel tank Bolt 8mm
2
30 22
Muffle
stay Bolt 6mm
2
11
8
Muffler and exhaust pipe Bolt 8mm
1
20 14
Muffler bracket and muffle
Bolt 8mm
1
20 14
Muffler bracket and frame Bolt 8mm
2
20 14
Muffler damper and muffle
Bolt 6mm
1
10 7.2
Muffler damper and frame Bolt 6mm
1
10 7.2
Exhaust pipe Nut 8mm
4
14 10
ir duct assembly 1 Bolt 6mm
2 7
5.1
ir duct assembly 2 and left protecto
Bolt 6mm
1 7
5.1
ir duct assembly 2 and frame Bolt 6mm
1 7
5.1
Gear position switch Bolt 5mm
2 7
5.1
Thermo switch 1 (cylinde
head)
1/8
1 8
5.8
Thermo switch 3 (radiator)
18 mm
1
28 20
Reverse switch
10 mm
1
20 14
Engine ground lead Bolt 6mm
1
10 7.2
Starter motor and engine Bolt 6mm
2
10 7.2
