PARTS AND HARDWARE LIST
1
3
4
1
PART #
518-0055
518-0030
518-0031
518-0032
518-0047
009-0007
001-0039
DESCRIPTION
CHL 500 Mower Lift
Hydraulic Cylinder - 2 Ton
Left Wheel Pad
Right Wheel Pad
Handle
Safety Straps
Push Pins
QTY.
1
1
1
1
1
2
2
ITEM
2
7
3
4
5
7
Push Pin
5
2
6
Safety Strap
6
The 3 locking positions are: 18” , 21”, 26”
T-Bar
FRONT OF LIFT
