9
SECTION 4: KNOW YOUR LAWN TRACTOR
Figure 2
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A Systems Indicator Monitor/Hour Meter H Ignition Switch Module
B Throttle Control Lever I Power Take-Off (PTO) Control Switch
C Choke Control J Brake Pedal
D 12 V Power Outlet K Drive Pedal
E Parking Brake Lever L Cruise Control Lever
F Fuel Tank Cap M Deck Lift Lever
G Seat Adjustment Lever N Cup Holder
I
B
A
H
C
E
F
M
L
K
G
J
N
NOTE: Steering Wheel not shown for clarity.
BRAKE
HOURS 1 /10
PARKING
OIL PRESSURE
PTO / BLADE ENGAGE
BATTERY
P
+
D
