13Section 4 — controlS & FeatureS
Low Gas Window
The low gas window is located at the rear of
the tractor. If the gas level is visible in this
window, the tank should be re-filled.
Transmission Bypass Rod
The transmission bypass rod is located at the rear of the tractor
on the lower right section of the frame.
When engaged, the rod opens a bypass within the hydrostatic
transmissions, which allows the tractor to be pushed short
distances by hand. Refer to the Assembly & Set-Up section for
instructions on using the bypass feature.
NOTE: If the tractor will not move or does not move freely when
pushing check if the bypass lever is fully open.
NOTE:
bypass rod is pulled out. Return the rod to its normal position
prior to operating the tractor. If the tractor will not move when
pushing on the forward/reverse pedals, or moves slowly, check to
see of the bypass valve is on.
CAUTION: Never tow your tractor. Towing the
tractor with the rear wheels on the ground may
cause severe damage to the transmissions.
Hydrostatic Transmission Oil Plug/Dipstick
The hydrostatic transmission oil plug/dipstick is located on the
back of the tractor frame and is used to check the level of the
hydrostatic transmission oil. The oil fill port is where hydrostatic
transmission oil can be added.
Systems Indicator Monitor/Hour Meter
PA
R
K
B
R
A
K
E
PTO /
BLA
D
E
O
I
LBATT.
FILL
TANK IF GAS
LEVEL IS SHOWN
IN WINDOW
LCD
into the START position, the systems indicator monitor displays the
after which it displays an hour glass and the hours of tractor
displays an hour glass and the hours of tractor operation on its LCD.
NOTE: Hours of tractor operation are recorded any time the
whether the engine is started.
The Indicator Monitor will also remind the operator of
maintenance intervals for changing the engine oil. The LCD will
minutes, after every 50 hours of recorded operation elapse. The
this maintenance interval. Before the interval expires, change the
Brake
If the Brake light illuminates when attempting to start the
PTO (Blade Engage)
Oil
while the engine is running, stop the tractor immediately and
Battery
It is normal for the Battery light to illuminate while the engine is
while the engine is running, the battery is in need of a charge
amperage. Charge the battery as instructed in the Service
section of this manual or have the charging system checked by
your Cub Cadet dealer.
