Cub Cadet GT 2521 User Manual

38
7. Lower the mower deck by moving the implement
lift handle to its lowest setting. Disengage the deck
idler arm lever from its stop bracket and release
the spring tension by rotating the lever out and
rearward (See Figure 52).
Figure 52
8. Remove the rearward end of the PTO belt from the
upper pulley of the deck center double-pulley
(Refer to Figure 53). Engage the deck idler arm
lever back into its stop bracket (See Figure 54).
Figure 53
Figure 54
WARNING
If the engine has been recently operated, the
exhaust system, engine, and surrounding areas
will be hot. To avoid personal injury, allow these
areas to cool before proceeding with the
following PTO belt removal instructions.
9. Open the tractor hood and remove the forward end
of the PTO belt from the PTO clutch pulley on the
front of the engine (See Figure 55).
Figure 55
10. Pass the PTO belt downward, inside the tractor
frame, until the belt is below the two tractor front
lower pulleys and pull the belt clear of the tractor
(See Figure 56).
Figure 56
IDLER ARM
LEVER
STOP
BRACKET
MOWER DECK
CENTER DOUBLE
PULLEY
PTO BELT
FRONT OF DECK
IDLER ARM
LEVER
STOP BRACKET
PTO
CLUTCH
PULLEY
PTO
BELT
