Cub Cadet GTX 1054 User Manual

PTO Belt
Rotate
Pulley
Figure 7-10
Pull the right side of the belt and place the narrow V side of 

While holding the belt and pulley together, rotate the  

rotating the pulley and belt until the belt is fully rolled into

Changing the Transmission Drive Belt
Several components must be removed and special tools used in

Cub Cadet dealer to have the transmission drive belt replaced.
29se c t i O n 7 — se r v i c e

Cub Cadet GTX 1054 Specifications

General

Engine Displacement	725 cc
Cutting Width	54 inches
Transmission	Hydrostatic
Deck Material	12-gauge steel
Deck Engagement	Electric PTO
Engine Size	725 cc
Horsepower	24 HP
Deck Size	54 inches
Blades	3
Turning Radius	16 inches
Engine Power	24 HP
Warranty	3-year limited
Front Tires	16 x 6.5 x 8
