Cub Cadet LT1042 Parts Manual

9
FRAME
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 17962 Plate, Switch 1
2 683-04173 Frame Assembly, Lower 1
3 683-0612 Bumper Assembly 1
4 710-0224 Screw, Hex Wash. Hd. Tapp, 10-16 x .5 2
5 710-0726 Screw, Self-tapping, 5/16-18, 0.75 13
6 710-1260A Screw, 5/16-18, 0.750 2
7 710-1652 Screw, Hex Wash. Hd. Tapp, 1/4-20 x 0.625 1
8 711-0332 Pin, Clevis, .50 Dia x .78 Lg 2
9 712-04065 Nut, Nylon Lock, 3/8-16 2
10 710-0607 Screw, Hex Wash. Tapp, 5/16-18 x .5 1
11 714-04023 Pin, Internal Cotter 2
12 741-04092 Snap Bushing 1
13 732-04035 Spring, Compression, 1.28 OD x 3.125 Lg 2
14 736-0222 Washer, Lock, Ext 1/4 2
16 738-04058 Shoulder Spacer 2
17 738-0143 Shoulder Screw, 3/8-16 2
18 710-3005 Hex Screw 3/8-16 x 1.25 2
19 783-0726D Bracket, Pivot, Support RH 1
20 783-0727C Bracket, Pivot, Support LH 1
21 783-0728 Bracket, Pivot, Bar 1
22 783-04330A Frame, Upper 1
23 783-04329A Bracket, Frame, Seat 1
24 725-04039 Switch, Interlock 1
25 751-0535 Fuel Line 1
26 726-0205 Clamp, Hose, .490 Dia. 2

Cub Cadet LT1042 Specifications

General

Style	Tractor
Color	Yellow
Cutting Width	-
Cutting Height	-
Cutting Method	Optional Side Discharge
Number of Blades	-
Drive System	Rear Wheel Drive
Case Size: U1R	12V
Noise Level	-
Features	Cruise Control
Accessories	-
Motor / Engine Model	Kohler Courage SV590
Power Output	-
Cylinders	1
Generator	-
Power / Fuel Type	Gasoline
Fuel Tank Volume	13.2 liters (3.5 US gal.; 2.9 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SG or SL
w/o Filter: 44 oz. (1	1.5 L (1.59 US. qt

Weight and Dimensions

Depth	1730 mm
Height	1090 mm
Width	1143 mm
Net Weight	226 kg
