Cub Cadet LTX 1046VT User Manual

To place the new belt begin by routing the belt around the 5.
two outer spindle pulleys, then around the front spindle
pulley as shown in Fig. 7-8.
Then route the belt around the two deck idler pulleys as 6.
shown in Fig. 7-8.
Retighten the belt keeper rod loosened earlier.7.
Remount the belt guards removed earlier8.
Reinstall the deck making sure the belt remains routed 9.
around the pulleys as instructed.


While holding the belt and pulley together, rotate the  
pulley to the left (See Fig. 7-9). Continue holding and
rotating the pulley and belt until the belt is fully rolled into

Outer Spindle
Pulleys
Front Spindle
Pulley
Deck Idler
Pulleys
Figure 7-8
PTO Belt
Rotate
Pulley
Figure 7-9
28 se c t i O n 7— se r v i c e

Cub Cadet LTX 1046VT Specifications

General

Engine Brand	Kohler
Engine Displacement	725cc
Cylinders	2
Cutting Width	46 inches
Transmission Type	Hydrostatic
Drive System	2WD
Deck Material	Steel
Cutting Height	1.5-4 inches
Blades	2
Engine Model	Courage
Turning Radius	18 inches
Front Tires	15 x 6 inches
Rear Tires	20 x 8 inches
Warranty	3-year limited
