Cub Cadet RZT Series User Manual

.
Unscrew and remove the dipstick; wipe oil off.
Reinsert the dipstick into the tube and rest the
cap on the tube. Do not screw the cap onto the
tube. See Figure 5.
Figure 5. Checking Oil Level.
4. Pull the dipstick out and check the oil level. The
oil level should be up to, but not over, the "FULL"
or "F" mark on the dipstick. See Figure 6.
Oil Sentry TM
Some engines are equipped with an optional Oil
Sentry TM oil pressure switch, if the oil pressure drops
below an acceptable level, the Oil Sentry TM will either
shut off the engine or activate a warning signal,
depending on the application.
NOTE: Make sure the oil level is checked BEFORE
EACH USE and is maintained up to the
"FULL" or "F" mark on the dipstick. This
includes engines equipped with Oil Sentry TM.
Change Oil and Filter, Service Oil Cooler
Change Oil and Oil Filter
Change the oil and oil filter annually or every 100
hours of operation (more frequently under severe
conditions). Refill with service class SG, SH, SJ, or
higher oil as specified in the "Viscosity Grades" table
(Figure 2) on page 4. Always use a genuine Kohter oil
filter. Use chart below to determine part number to
order.
Oil Filter Part No. Length
12 050 01-S 2-1/2"
52 050 02-S 3-3/8"
Change the oil while the engine is still warm. The oil
will flow more freely and carry away more
impurities. Make sure the engine is level when filling,
checking, or changing the oil.
Figure 6. Oil Level Dipstick (Typical).
.
if the level is low, add oil of the proper type, up to
the "FULL" or "F" mark on the dipstick. (Refer to
"Oil Type" on page 4.) Always check the level
with the dipstick before adding more oil.
NOTE:
To prevent extensive engine wear or damage,
always maintain the proper oil level in the
crankcase. Never operate the engine with the
oil level below the "ADD" or "L" mark or
above the "FULL" or "F" mark on the
dipstick.
4.
Remove dipstick and check oil level. The level
should be between the "Full or F" and "Add or L"
marks. If low, add oil of the proper type up to the
full mark. Reinstall oil fill cap/dipstick and screw
tight.
Figure 7. Oil Drain Plug.
Oil Filter
Figure 8. Oil Filter Location.

Cub Cadet RZT Series Specifications

General

Transmission	Hydrostatic
Type	Zero-Turn
Engine	Kohler, Kawasaki, or Cub Cadet
Cutting Width	42 inches
Fuel Capacity	2.5-3.5 gallons
Turning Radius	Zero-Turn
Deck Material	Fabricated Steel
Weight	500-700 lbs
Warranty	3-year
