13se c t i O n 2 — as s e M b l y & se t -up
To adjust the tilt of the steering wheel:
2.
place by pushing the adjustment lock lever forward until
the steering wheel is secure.
In the neutral position with hands on the steering wheel,
approximately vertical.
Check the results of any adjustments to the conditions described
above. Repeat any adjustment procedures as required until all
conditions are met.
Figure 3-10
Suspension Seat
This tractor is equipped with an adjustable suspension seat
system, which includes a seat with retractable seat belt assembly,
the seat bottom and is connected to the machine electrical
system.
The seat has several adjustments to meet the individual needs of
Seat Position
To adjust the position of the seat, pull forward and hold the
to the desired position; then release the adjustment lever.
Make sure seat is locked into position before operating the
tractor.
Arm Rests
To adjust to the arm rest rotate the roller bearing, single-
locking knob on the bottom of the arm. The angle of the
arm can move up or down.
Mechanical Suspension Mechanism
To adjust the mechanical suspension mechanism, there
is a lever on the front of the seat with an orange colored
indicator arrow and guage.
2.
center of the seat, flip the lever out towards the right and
orange-colored indicator on the guage to achieve your
exact weight setting.
Lumbar Support
the lumbar support from the top portion of the seat, to the
lower portion and off. Rotate the knob to set the support to
the desired area.
Seat Adjustment
Lever
Mechanical Suspension
Mechanism
Lumbar
Support
Knob
Arm Rest
Adjustments
Figure 3-11
