16 se c t i O n 4— cO n t r O l s & fe a t u r e s
Digital Tachometer and Hour Meter
hours that the tractor has been operated in the digital display.
reminders (oil, lube) in the digital display.
The tachometer/hour meter is activated all the time, but does
not consume power form the battery. Keep a record of the actual
hours of operation to assure all maintenance procedures are
completed according to the instructions in this manual and the
engine manual.
Throttle Control
engine speed will be maintained. The trottle control moves
between the fast
and slow positions.
speed. The tractor is designed to operate with the throttle
control in the fast position
(full throttle) when the tractor is
being driven and the mower deck is engaged.
speed.
Parking Brake
The parking brake is located on the left side of
the tractor and to the left side of the brake pedal.
at the same time until it latches to engage the
release to disengage the parking brake.
NOTE: If the speed control pedals are not in the
neutral position when engaging the parking
brake, the engine will stop. The parking brake must be placed in
the engaged position when starting the tractor engine.
Speed Control Pedals
The speed control pedals are located on the right side of the
traction unit. The speed control pedals must be in the neutral
position to start the tractor engine.
Consequently, these pedals control all of the movements of the
tractor. Driving and steering utilizing these control pedals is quite
different from conventional tractors, and will take some practice
using the speed control pedals.
Ignition Switch
has three positions as follows:
off.
RUN — The tractor electrical system is energized.
key immediately when the engine starts
NOTE: To prevent accidental starting and/or battery discharge,
remove the key from the ignition switch when the tractor is not
in use.
PTO (Power Take-Off) Switch
ignition switch.
clutch mounted on the bottom of the engine
downward to disengage the clutch.
position when starting the engine.
Fuel Valve
turned in a clockwise direction until it stops, it will shut off the
flow of fuel to the engine. When turned in a counter-clockwise
direction it will open and allow fuel to flow to the engine.
Fuel Gauge
tanks, the fuel gauge measures the
fuel level in each tank.
