39se c t i O n 7 — se r v i c e
Changing the Spindle Assembly
block it in that position.
Make sure the blade clutch is disengaged.2.
Remove the deck cover.
4.
5.
Using a wrench or socket ratchet remove flange lock 6.
nuts, and the four hex flange bolts. Remove the spindle
Reverse the process to install the spindle assembly.7.
Tractor Creeping
Creeping is the slight forward or backward movement of the
mower when the throttle is on and the speed control pedals are
in the neutral position. If your mower creeps, see an authorized
service dealer.
Spindle Assembly
Blade
Flange Lock Nut
Spacer
Hex Flange Bolt
Support Plate
Flange Lock Nut
Hex Screw
Figure 7-5
