Cub Cadet SC 100 User Manual

Assembly & Set-Up
3
9
Contents of Carton
• One Lawn Mower • One Grass Catcher • One Bottle of Oil
• One Lawn Mower Operator’s Manual • One Engine Operator’s Manual • One Side Discharge Chute
B
Figure 3-2
2. Remove the T-bolts from the handle brackets as shown in
Figure 3-3.
Figure 3-3
Assembly
NOTE: This unit is shipped without gasoline or oil in the engine.
Fill up with gasoline and oil as instructed in the accompanying
engine manual BEFORE operating your mower.
Handle
1. Remove any packing material which may be between
upper and lower handles.
a. Remove wing nuts and carriage bolts from handle
as shown in Figure 3-1. Do not loosen or remove
adjacent hex head screws.
A
A
Figure 3-1
b. While stabilizing mower so it doesn’t move, pivot
upper handle up as shown in Figure 3-2. Do not
crimp cables while lifting the handle up.

Cub Cadet SC 100 Specifications

General

Cutting Width	21 inches
Deck Material	Steel
Cutting Height Range	1.25 to 3.75 inches
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Wheel Size	7 inches front, 8 inches rear
Self-Propelled	No
Starter Type	Recoil
Drive Type	Push
Fuel Tank Capacity	1.3 quarts
