Sc Series 7 Sc2450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-119717-01501 CASE, GEAR 1
2 CY-119717-01570 BOLT, STUD M8 3
3 CY-119734-01580 COVER ASSY,GEAR CASE 1
4 N/A COVER ASSY,GEAR CASE (ORDER REF NO.3) 1
5 N/A COVER, GEAR CASE (ORDER REF NO.3) 1
6 CY-119717-01800 SEAL, OIL 1
7 CY-23876-030000 PLUG PT3/8,SCREW 2
8 CY-119717-32100 COVER ASSY, PUMP 1
9 N/A COVER, LUB.OIL PUMP (ORDER REF NO.8) 1
10 CY-129900-32130 VALVE, RELIEF 1
11 CY-129001-32320 SPRING 1
12 CY-129001-32330 PLUG 1
13 CY-119717-32110 ROTOR, INNER 1
14 CY-119717-32120 ROTOR, OUTER 1
15 CY-119802-32130 SCREW, M6X16 8
16 CY-119717-01750 COVER, PUMP TIMING 1
17 CY-119660-01911 PIPE, KNOCK 4
18 CY-119624-32040 O-RING P 12.0 1
19 CY-119717-32050 O-RING, P17.0 3
20 CY-121850-51960 O-RING, F.I.PUMP 1
21 CY-26106-060122 BOLT M 6X 12 PLATED 1
22 CY-26106-060162 BOLT M 6X 16 PLATED 4
23 CY-26106-060402 BOLT M 6X 40 PLATED 4
24 CY-26106-060402 BOLT M 6X 40 PLATED 3
25 CY-26106-060602 BOLT M 6X 60 PLATED 7
26 CY-26106-060652 BOLT M 6X 65 PLATED 2
27 CY-26306-080002 NUT 3
28 CY-124160-01751 COVER,FILLER 1
29 CY-24311-000320 O-RING 1A P-32.0 1
30 CY-129150-91400 GEAR UNIT,TACHOMETER 1
32 CY-24341-000240 O-RING 1A S-24.0 1
33 CY-26106-060162 BOLT M 6X 16 PLATED 2
FIG. 2. GEAR HOUSING
