2
1 IM-115253421 Crankshaft ........................ 1
2 IM-034309031 Key ................................... 1
3 IM-115013300 Piston Assembly (Includes
2 Ref. 4) ............................ 1
4 IM-115113650 Ring, Piston ...................... 2
5 IM-115323130 Pin, Piston ........................ 1
6 IM-198343210 Clip, Piston Pin ................. 2
7 IM-042709007 Bearing, Needle ................ 1
8 IM-110035180 Crankcase Assembly
(Includes 1 ea. Ref. 9,10
and 2 ea. Ref. 11) ............. 1
9 IM-040106000 Bearing, Ball, 6000 ........... 1
10 IM-050209097 Seal, Oil ............................ 2
11 IM-030500512 Pin, Dowel ........................ 2
12 IM-110035131 Crankcase Assembly
(Includes 1 ea. Ref. 10
and 19) ............................. 1
13 IM-199283050 Shim, 0.1mm .......As Req’d.
IM-199283060 Shim, 0.2mm .......As Req’d.
14 IM-155353090 Pulley Assembly, Starter
(Includes 1 ea. Ref.15 and
91) .................................... 1
15 IM-155163110 Ratchet ............................. 1
16 IM-155103461 Recoil Assembly (Includes
1 ea. Ref.17, 18, 88, 89
and 90) ............................. 1
17 IM-155213050 Rope, Starter .................... 1
18 IM-155223061 Knob, Starter .................... 1
19 IM-040106200 Bearing, Ball, 6200 ........... 1
20 IM-190285420 Name Plate ....................... 1
21 IM-150053291 Coil Assembly, Ignition ...... 1
22 IM-199513451 Insulator ............................ 1
23 IM-010709018 Bolt, M4x20....................... 2
24 IM-198213300 Spring ............................... 1
25 IM-150413033 Cap, Plug .......................... 1
Ref. Parts No.
No. No. Description Used
ENGINE, ST23 TRIMMER – PARTS LIST
26 IM-150265091 Spark Plug ........................ 1
27 IM-150103460 Flywheel, Magneto ........... 1
28 IM-170033220 Clutch Assembly ............... 1
29 IM-199213150 Spacer .............................. 2
30 IM-199213221 Spacer .............................. 2
31 IM-199433071 Bolt ................................... 2
32 IM-020109118 Nut .................................... 1
33 IM-010709009 Bolt, M5x20....................... 5
34 IM-175103460 Housing, Blower ............... 1
35 IM-010709008 Bolt, M5x16....................... 8
36 IM-170333220 Drum, Clutch..................... 1
37 IM-036100010 Snap Ring, S-10 ............... 1
38 IM-298111010 Grommet........................... 1
40 IM-010709011 Bolt, M5x30 ....................... 1
41 IM-020109131 Nut .................................... 1
42 IM-110213550 Cylinder ............................ 1
43 See Ref.86 - Gasket, Muffler ..................... 1
44 IM-135403500 Muffler ............................... 1
45 IM-135493090 Arrester ............................. 1
46 IM-110993390 Gasket, Cylinder ............... 1
47 IM-010709016 Bolt, M5x48....................... 4
48 IM-175154060 Cowling, Cylinder .............. 1
49 IM-135433470 Baffle Plate ....................... 1
50 IM-190333330 Trade Mark ....................... 1
51 See Ref.86 - Gasket, Insulator .................. 1
52 IM-199513501 Insulator ............................ 1
53 IM-125543100 Adjuster ............................ 1
54 IM-010709006 Bolt, M5x12....................... 4
55 IM-020100005 Nut .................................... 1
56 IM-026100005 Washer ............................. 2
57 IM-010709010 Bolt, M5x25....................... 2
58 See Ref.86 - Gasket .................................. 1
59 IM-130104240 Carburetor Assembly
(Includes 1 ea. Ref. 60, 61,
62, 63, 64 and 65) ............ 1
60 IM-130153240 Valve, Float ....................... 1
61 IM-130123350 Gasket .............................. 1
62 IM-130283357 Diaphragm, Metering ........ 1
63 IM-130513409 Diaphragm, Pump ............. 1
64 IM-130513413 Gasket .............................. 1
65 IM-198113900 Rubber .............................. 1
66 IM-135713490 Case, Air Silencer ............. 1
67 IM-135263310 Element “B”, Air Filter ....... 1
68 IM-135263300 Element “A”, Air Filter ....... 1
69 IM-135713480 Cap, Case ......................... 1
70 IM-125504680 Wire Complete, Throttle .... 1
71 IM-160113270 Tank, Fuel ......................... 1
72 IM-160033200 Cap Assembly, Fuel Tank
(Includes 1 Ref. 73) ......... 1
73 IM-160993100 Gasket .............................. 1
74 IM-130303290 Filter, Fuel ......................... 1
75 IM-198343181 Clip ................................... 1
76 IM-130983060 Hose ................................. 1
77 IM-198113730 Rubber .............................. 1
78 IM-068209150 Hose ................................. 1
79 IM-198113560 Rubber .............................. 1
80 IM-068209177 Hose ................................. 1
81 IM-160043121 Valve, Reversing ............... 1
82 IM-198343060 Clip ................................... 1
83 IM-198483100 Connector ......................... 1
84 IM-198113701 Rubber .............................. 2
85 IM-198113740 Rubber .............................. 1
86 IM-135994150 Gasket Kit (Includes 1 ea.
Ref. 43, 51 and 58) ........... 1
87 IM-125683061 Wire Holder ....................... 1
88 IM-155183121 Reel .................................. 1
89 IM-155263270 Spring, Spiral .................... 1
90 IM-155343050 Screw ................................ 1
91 IM-155263261 Spring, Return .................. 1
Ref. Parts No.
No. No. Description Used
Ref. Parts No.
No. No. Description Used
To Next Page
