2
1 IM-115253470 Crankshaft ........................ 1
2 IM-115013311 Piston Assembly (Includes
2 Ref. 3) ............................ 1
3 IM-115113650 Ring, Piston ...................... 2
4 IM-115323040 Pin, Piston ........................ 1
5 IM-198343210 Clip, Piston Pin ................. 2
6 IM-042709008 Bearing, Needle ................ 1
7 IM-110035190 Crankcase Assembly
(Includes 1 ea. Ref. 8,9
and 2 ea. Ref. 10) ............. 1
8 IM-040106201 Bearing, Ball, 6201 ........... 2
9 IM-050209070 Seal, Oil ............................ 2
10 IM-030500512 Pin, Dowel ........................ 2
11 IM-110035200 Crankcase Assembly
(Includes 1 ea. Ref. 8 and
9) ...................................... 1
12 IM-010709010 Bolt, M5x25....................... 5
13 IM-155353090 Pulley Assembly, Starter
(Includes 1 ea. Ref.14 and
86) .................................... 1
14 IM-155163110 Ratchet ............................. 1
15 IM-155103461 Recoil Assembly (Includes
1 ea. Ref.16, 17, 83, 84
and 85) ............................. 1
16 IM-155213050 Rope, Starter .................... 1
17 IM-155223061 Knob, Starter .................... 1
18 IM-190285440 Name Plate ....................... 1
19 IM-150053330 Coil Assembly, Ignition ...... 1
20 IM-010709018 Bolt, M4x20....................... 2
21 IM-198213300 Spring ............................... 1
22 IM-150413033 Cap, Plug .......................... 1
23 IM-150265091 Spark Plug ........................ 1
24 IM-150103500 Flywheel, Magneto ........... 1
25 IM-170033370 Clutch Assembly ............... 1
Ref. Parts No.
No. No. Description Used
ENGINE, ST26 TRIMMER – PARTS LIST
26 IM-010709009 Bolt, M5x20....................... 4
27 IM-175103470 Housing, Blower ............... 1
28 IM-010709008 Bolt, M5x16....................... 5
29 IM-170333240 Drum, Clutch..................... 1
30 IM-036100012 Snap Ring, S-12 ............... 1
31 IM-199233470 Collar ................................ 1
32 IM-010709011 Bolt, M5x30 ....................... 1
33 IM-020109131 Nut .................................... 1
34 IM-175423050 Plate ................................. 1
35 IM-198113890 Rubber .............................. 1
36 IM-110213560 Cylinder ............................ 1
37 See Ref.80 - Gasket, Muffler ..................... 1
38 IM-135403670 Muffler (Includes 1 Ref.39) 1
39 IM-135493090 Arrester ............................. 1
41 IM-010709016 Bolt, M5x48....................... 2
42 IM-175154070 Cowling, Cylinder.............. 1
43 IM-135433630 Baffle Plate ....................... 1
44 IM-190333330 Trade Mark ....................... 1
45 See Ref.80 - Gasket, Insulator .................. 1
46 IM-010109433 Bolt, M5x56....................... 2
47 IM-199513510 Insulator ............................ 1
48 IM-125543100 Adjuster ............................ 1
49 IM-010709006 Bolt, M5x12....................... 1
50 IM-020100005 Nut .................................... 1
51 IM-026100005 Washer ............................. 2
52 See Ref.80 - Gasket .................................. 1
53 IM-130104240 Carburetor Assembly
(Includes 1 ea. Ref. 54, 55,
56, 57, 58 and 59) ............ 1
54 IM-130153240 Valve, Float ....................... 1
55 IM-130123350 Gasket .............................. 1
56 IM-130283357 Diaphragm, Metering ........ 1
57 IM-130513409 Diaphragm, Pump ............. 1
58 IM-130513413 Gasket .............................. 1
59 IM-198113900 Rubber .............................. 1
60 IM-135713490 Case, Air Silencer ............. 1
61 IM-023100005 Nut .................................... 2
62 IM-135263310 Element “B”, Air Filter ....... 1
63 IM-135263300 Element “A”, Air Filter ....... 1
64 IM-135713450 Cap, Case ......................... 1
65 IM-125504790 Wire Complete, Throttle .... 1
66 IM-160113261 Tank, Fuel ......................... 1
67 IM-160033200 Cap Assembly, Fuel Tank
(Includes 1 Ref. 78) .......... 1
68 IM-160993100 Gasket .............................. 1
69 IM-130303290 Filter, Fuel ......................... 1
70 IM-198343181 Clip ................................... 1
71 IM-198163080 Hose ................................. 1
72 IM-198113730 Rubber .............................. 1
73 IM-068209150 Hose ................................. 2
74 IM-198113560 Rubber .............................. 1
75 IM-160043121 Valve, Reversing ............... 1
76 IM-198343060 Clip ................................... 1
77 IM-198483100 Connector ......................... 1
78 IM-198113620 Rubber .............................. 2
79 IM-198113740 Rubber .............................. 1
80 IM-135994160 Gasket Kit (Includes 1 ea.
Ref. 37, 45 and 52) ........... 1
81 IM-125683061 Wire Holder ....................... 1
82 IM-110993420 Gasket, Cylinder ............... 1
83 IM-155183121 Reel .................................. 1
84 IM-155263270 Spring, Spiral .................... 1
85 IM-155343050 Screw ................................ 1
86 IM-155263261 Spring, Return .................. 1
Ref. Parts No.
No. No. Description Used
Ref. Parts No.
No. No. Description Used
