2
1 IM-115253440 Crankshaft ........................ 1
2 IM-034309031 Key ................................... 1
3 IM-115013280 Piston Assembly (Includes
2 Ref. 4) ............................ 1
4 IM-115113730 Ring, Piston ...................... 2
5 IM-115323030 Pin, Piston ........................ 1
6 IM-198343040 Clip, Piston Pin ................. 2
7 IM-042709006 Bearing, Needle ................ 1
8 IM-110035150 Crankcase Assembly
(Includes 1 ea. Ref. 9 and
10) .................................... 1
9 IM-040106201 Bearing, Ball, 6201 ........... 2
10 IM-050209070 Seal, Oil ............................ 2
11 IM-110035160 Crankcase Assembly
(Includes 1 ea. Ref. 9, 10
and 4 ea. Ref. 12) ............. 1
12 IM-030500512 Pin, Dowel ........................ 4
13 IM-199283030 Shim, 0.1mm ....... As Req’d.
IM-199283040 Shim, 0.2mm .......As Req’d.
14 IM-010709011 Bolt, M5x30 ....................... 4
15 IM-155353060 Pulley Assembly, Starter
(Includes 1 ea. Ref. 16 and
101) .................................. 1
16 IM-155163080 Ratchet ............................. 1
17 IM-020300008 Nut .................................... 1
18 IM-155103341 Recoil Assembly (Includes
1 ea. Ref.19, 20, 21, 99
and 100) ........................... 1
19 IM-155263210 Spring, Sprial .................... 1
20 IM-155223050 Knob, Starter .................... 1
21 IM-155213090 Rope, Starter .................... 1
22 IM-010709008 Bolt, M5x16..................... 16
23 IM-190285460 Name Plate ....................... 1
24 IM-150103351 Flywheel, Magneto ........... 1
25 IM-020109107 Nut .................................... 1
26 IM-170033241 Clutch Assembly ............... 1
27 IM-199213071 Spacer .............................. 2
28 IM-199213180 Spacer .............................. 2
29 IM-199433082 Bolt ................................... 2
Ref. Parts No.
No. No. Description Used
ENGINE, ST35 TRIMMER – PARTS LIST
30 IM-170333140 Drum, Clutch..................... 1
31 IM-036500035 Snap Ring, R-35 ............... 1
32 IM-040126202 Bearing, Ball, 6202ZZ ....... 1
33 IM-036100015 Snap Ring, S-15 ............... 1
34 IM-175114580 Housing, Blower ............... 1
35 IM-298111010 Grommet ........................... 1
36 IM-198113810 Rubber .............................. 1
37 IM-165983130 Pipe .................................. 1
38 IM-036550047 Snap Ring, R-47 ............... 1
39 IM-010709015 Bolt, M4x12....................... 2
40 IM-010709013 Bolt, M6x20....................... 1
41 IM-125504840 Wire Complete, Throttle.... 1
43 IM-150053320 Coil Assembly, Ignition ...... 1
44 IM-198213300 Spring ............................... 1
45 IM-150413033 Cap, Plug .......................... 1
46 IM-150265091 Spark Plug ........................ 1
47 IM-010709009 Bolt, M5x20....................... 2
48 IM-110213540 Cylinder ............................ 1
49 IM-110993410 Gasket, Cylinder ............... 1
50 See Ref.95 - Gasket, Muffler ..................... 1
51 IM-135403492 Muffler ............................... 1
52 IM-010709040 Bolt, M5x58....................... 2
53 IM-010709006 Bolt, M5x12....................... 4
54 See Ref.95 - Gasket, Baffle Plate.............. 1
55 IM-135493010 Arrester ............................. 1
56 IM-135433570 Baffle Plate, Outer ............ 1
57 IM-010709014 Bolt, M4x6......................... 4
58 IM-135433560 Baffle Plate ....................... 1
59 See Ref.95 - Gasket, Insulator .................. 1
60 IM-199513550 Insulator ............................ 1
61 IM-026100005 Washer ............................. 2
62 IM-010709010 Bolt, M5x25....................... 2
63 IM-125543090 Adjuster ............................ 1
64 IM-135263370 Element “B”, Air Filter ....... 1
65 See Ref.95 - Gasket .................................. 1
66 IM-130104210 Carburetor Assembly
(Includes 1 ea. Ref. 67, 68,
69, 70, 71 and 72) ............ 1
67 IM-130153210 Valve, Float ....................... 1
68 IM-130123350 Gasket .............................. 1
69 IM-130283357 Diaphragm, Metering ........ 1
70 IM-130513409 Diaphragm, Pump ............. 1
71 IM-130513410 Gasket .............................. 1
72 IM-198113870 Rubber .............................. 1
73 See Ref.95 - Gasket, Air Silencer .............. 1
74 IM-135713373 Case, Air Silencer ............. 1
75 IM-010709016 Bolt, M5x48 ....................... 2
76 IM-135263380 Element “A”, Air Filter ....... 1
77 IM-135713393 Cap, Case (Includes 1
Ref. 78) ............................. 1
80 IM-160103330 Tank, Fuel ......................... 1
81 IM-130303290 Filter, Fuel ......................... 1
82 IM-198343181 Clip ................................... 1
83 IM-198163080 Hose ................................. 1
84 IM-160033200 Cap Assembly, Fuel Tank
(Includes 1 Ref. 85) .......... 1
85 IM-160993100 Gasket .............................. 1
86 IM-175973400 Stay, Stand ....................... 1
87 IM-175154080 Cowling, Cylinder .............. 1
88 IM-190333330 Trade Mark ....................... 1
89 IM-198113730 Rubber .............................. 1
90 IM-068209150 Hose ................................. 1
91 IM-160043121 Valve, Reversing ............... 1
92 IM-068209176 Hose ................................. 1
93 IM-198113560 Rubber .............................. 1
95 IM-135994170 Gasket Kit (Includes 1 ea.
Ref.50, 54, 59, 65 and 73) 1
96 IM-198343060 Clip ................................... 1
97 IM-198483100 Connector ......................... 1
98 IM-125683061 Wire Holder ....................... 1
99 IM-155183090 Reel .................................. 1
100IM-155343050 Screw ................................ 1
101IM-155263200 Spring, Return .................. 1
102IM-198113940 Rubber .............................. 1
Ref. Parts No.
No. No. Description Used
Ref. Parts No.
No. No. Description Used
