19Section 4 — controlS & FeatureS
Deck Lift Release Lever
The deck lift release lever is located on the left side of the
operator’s seat and is used to lock the deck in the transport
position. Press down on the deck lift pedal and lift up on the
deck lift release lever to release the deck.
Fuel Valve
The fuel valve is located on the fuel tank. The fuel valve can shut
off the flow of feul to the engine by turning the knob to the right.
To re-open the valve, turn the valve to the left.
Accessory Switch Receptacles
The three receptacles for
optional accessories are
on the RH console. See the
Attachments & Accessories
section for information. The
receptacles are for switches
for an optional electric deck
lift, lights and/or an auxiliary switch.
Transmission Bypass Levers
The transmission bypass levers (one for each the RH and LH
transmission) are located under the tractor on the front of each
transmission inside the rear wheels. The levers are connected to
a valve bracket that allows the levers to be controlled from the
parking brake.
When engaged the two valves open a bypass within the
hydrostatic transmissions. Refer to the Assembly & Set-Up
section for instructions on using the bypass feature.
AUX. LIGHTS
LIFT
