Section 6— Maintenance & adjuStMentS26
OIL CHART
Apply a few drops of SAE engine oil,
grease, or use a spray lubricant. Apply
the oil to both sides of pivot points. Wipe
off any excess. Start engine and operate
mower briefly to insure that oil spreads
evenly.
LUBRICATION CHART
Use a grease-gun filled with NO. 2
Multipurpose Lithium Base Grease
Number of Oil Points Description
DAILY
4 Deck Suspension Pivots
4 Height Adjustment Turnbuckle Clevis Pin
2 Height Adjustment Handle Pivots
2 Height Adjustment Stop Pivots
2 Deck Lift Linkage Pivots
2 Transport Handle Pivots
1 Transport Handle Pin
2 Deck Frame Up-and-Down Pivots
WEEKLY
1 Seat Hinge
2 Steering Lever Linkage Rod End Bearings
2 Lever Return Assembly Rod End Bearings
2 Pump Control Lever Pivots
1 Brake Lever Pivot Clevis Pin
1 Brake Lever Control Rod Pivot
1 Brake Control Rod Swivel Joint
4 Brake Rod Clevis Pins
2 Brake Shaft Assembly Pivots
2 Grass Collection System Lid Hinges (If Mower is so equipped)
Number of Grease Fittings Description
EVERY 25 HOURS
3 Blade Spindle Bearings
WEEKLY
2 Front Caster Wheels
2 Front Caster Wheel Spindles
2 Mower Deck Ball Wheels
Number of Grease Points Description
WEEKLY
4 Mowing Deck Pivots
2 Deck Take-Up Idler Pivots
1 Axle Pivot
2 Steering Lever Pivots
1 Hydro Take-up Idler Pivot
1 Park Brake Pivot
Engine Oil: Shell Rimula 15W40 or Rotella® T™ Triple Protection® 15W40 recommended.
Hydrostatic Fluid: Castrol™ (Syntec®) Edge™ 5W50 recommended.
Spindle Lubricant: Use only Shell Alvania RL 2 grease. This grease is an amber-colored grease designed for high speed bearing
applications. It has a base oil viscosity that reduces running losses, has been formulated for low noise, has excellent corrosion
protection, and has excellent bearing lubrication.
General Purpose Lubrication: Use any NLGI grade 2 multi-purpose grease. Shell Albida EP2 is recommended. Shell Albida EP 2
is a red-colored multi-purpose grease designed for heavy-duty bearing applications. It has high base oil viscosity for mechanical
stability, has been formulated for high load, low-speed applications, and has excellent lubrication and corrosion protection.
