Cub Cadet Yanmar Lx450 - Page 45

Lx450Lx Series
Ref.
Part Number Description Qty
1 CY-1A8250-03100 MUFFLER PIPE 1
2 CY-129052-13550 GASKET 1
3 CY-26106-080202 BOLT M 8X 20 PLATED 3
Copyright 2011 Cub Cadet Yanmar LLC
45
Fig 8. Exhaust
Fig.8. EXHAUST
0CNP5-G37900
0CNP5-G37900
8. EXHAUST
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
MUFFLER PIPE1A8250-0310011 111
GASKET129052-1355012 111
BOLT M 8X 20 PLATED26106-08020213 333
(C)Copy Rights YANMAR CO.,LTD.
