Cub Cadet Yanmar Lx450 User Manual

Lx450Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
5
Fig 1. Cylinder Block
Ref.
Part Number Description Qty
1 CY-729659-01570 BLOCK ASSY, CYLINDER 1
4 CY-124060-01050 PLUG, PT1/8 1
5 CY-129001-01250 PLUG, 50 1
6 CY-124160-01910 PLUG, PT1/4 2
7 CY-171051-01921 PLUG, NPTF1 1
8 CY-129150-02020 BOLT, METAL CAP 10
11 CY-129795-02412 BUSH, CAMSHAFT A 1
12 CY-27241-120000 PLUG, 12 2
13 CY-27243-300000 PLUG 30 8
23 CY-129150-02931 METAL ASSY, THRUST 2
26 CY-129150- 01200 BOLT, CYLINDER HEAD 18
27 CY-129407-01340 GASKET, CYL.HEAD 1
28 CY-119309-01810 PLUG 1
29 CY-129001-02931 MAIN BEARING SET 5
32 CY-129150-02871 MAIN METAL US=0.25 5
35 CY-129150-02941 BEARING, THRUST.25OS 1
