Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194555-46300 VALVE, STOP 1
2 CY-1A8275-46620 BOLT,STOP 1
3 CY-194312466303 HOLDER,VALVE 1
4 CY-22117-080000 WASHER 8 1
5 CY-22351- 040012 SPRING PIN 4X12 1
6 C Y-24 311- 0 0 0110 O-RING 1A P-11.0 2
7 CY-24311-000120 O-RING 1A P-12.0 1
Copyright 2011 Cub Cadet Yanmar LLC
151
Fig 81. Stop Valve
Fig.81. STOP VALVE
0CNP5-G37900
0CNP5-G37900
81. STOP VALVE
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
VALVE, STOP194555-4630011 111
BOLT,STOP1A8275-4662012 111
HOLDER,VALVE194312-46630-313 111
WASHER 822117-08000014 111
SPRING PIN 4X1222351-04001215 111
O-RING 1A P-11.024311-00011016 222
O-RING 1A P-12.024311-00012017 111
