Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
171
Fig 94. Harness
Ref.
Part Number Description Qty
1 CY-194990-22130 NUT W/WASHER 6 1
2 CY-194990-22140 NUT W/WASHER 8 1
3 CY-1A8275-51110 HARNESS A,ROPS(CMP 1
4 CY-1A7500-51130 DIODE, 3.0A 2
5 CY-1A7500-51170 CLIP, HARNESS 17
6 CY-1A8275-51190 LEAD,M-PTO 1
7 CY-1A8300-51230 COUPLER,PROTECT 1
8 CY-198535-52110 FUSE 7
9 CY-198535-52130 FUSE 15A 4
10 CY-198535-52140 FUSE 20A 2
11 CY-1A7531-52420 COVER, FUSE BOX 1
12 CY-1A7000-52820 SLOW BLOW FUSE60A 3
13 CY-1A8275-65440 LABEL,FUSE 1
14 CY-1E8775-84120 BAND CLAMP 20
15 CY-1A8275-51180 LEAD 1
16 CY-1A8300-51210 BAND, REPEAT 1
17 CY-1A8300-51210 BAND, REPEAT 1
18 CY-198155-51290 GROMMET D25 2
19 CY-1A7180-51350 CABLE, BATTERY PULUS 1
20 CY-194250-51420 CABLE, BATTERY EARTH 1
21 CY-198121-51430 CLAMP, B.CABLE 1
22 CY-194680-51670 BAND 3
23 CY-194680-51670 BAND 1
24 CY-198200-61490 GROMMET, 8 1
25 CY-124550 -77030 COVER, TERMINAL 1
26 CY-26106-060202 BOLT M 6X 20 PLATED 2
27 CY-26106-080162 BOLT M 8X 16 PLATED 1
28 CY-26106-080162 BOLT M 8X 16 PLATED 1
29 CY-26106-080162 BOLT M 8X 16 PLATED 1
30 CY-26106-080162 BOLT M 8X 16 PLATED 1
31 CY-26106-080252 BOLT M 8X 25 PLATED 1
32 CY-194440-51620 CLAMP, WIRE HARNESS 1
33 CY-26106-080162 BOLT M 8X 16 PLATED 1
