Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
27
Fig 12. Lub. Oil Line
Ref.
Part Number Description Qty
1 CY-114250-39450 SWITCH, OIL PRESSURE 1
2 CY-129558-39610 PIPE ASSY, LO RETURN 1
3 CY-123910-39850 RETAINER 1
4 CY-129558-39640 LO-T,T/C RETURN 1
5 CY-129558-39651 ELBOW,3/8 LO RETURN 1
6 CY-123957-39671 JOINT, PIPE 1
7 CY-23000-025000 CLAMP 25 2
8 CY-24316-000160 O-RING 4D P-16.0 1
9 CY-26106-060122 BOLT M 6X 12 PLATED 2
10 CY-26106-080122 BOLT M 8X 12 PLATED 1
11 CY-124160 -39140 BOLT, JOINT M10 1
12 CY-121252-39150 BOLT, PIPE JOINT 1
13 CY-129558-39480 PIPE ASSY, LUB. OIL 1
15 CY-119802-39500 RETAINER, PIPE 1
16 CY-124223-39900 RETAINER 1
17 CY-129005-59830 BOLT ASSY, JOINT 1
18 CY-22190-080002 SEAL WASHER 8S 1
19 CY-23857-030000 JOINT BOLT 3 1
20 CY-22190-080002 SEAL WASHER 8S 1
21 CY-22190-100002 WASHER, 10 2
22 CY-23414-100000 GASKET 10, ROUND 2
23 CY-26106-080122 BOLT M 8X 12 PLATED 1
24 CY-26366-060002 NUT M 6 1
25 CY-129792-39410 VALVE ASSY, CHECK 4
31 CY-129553-39650 NOZZLE, COOLING 4
32 CY-22351-030010 SPRING PIN 3X10 4
