Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
45
Fig 4. Engine Accessories Lx490
Ref.
Part Number Description Qty
1 CY-1A7140-00600 RADIATOR ASSY 1
2 CY-1A7180-01050 RUBBER,RADIATOR 2
3 CY-1A8250-01210 TUBE,COOLING WATER A 1
4 CY-1A7300-01220 PIPE, COOLING WATER 1
5 CY-1A7300-01230 PIPE, COOLING WATER 1
6 CY-1A8260-01241 CW-T, LO COOLER OUT 1
7 CY-1A8250-01250 SCREEN, RADIATOR 1
8 CY-1A8260-01260 JOINT, WATER COOLING 1
9 CY-194150-01270 SPACER 20 1
10 CY-1A8250-01500 SHROUD M ASSY, FAN 1
11 CY-198280-04470 JOINT 1
12 CY-1A8240-04620 CLAMP, FUEL HOSE 1
13 CY-1A8260-05100 CLEANER ASSY, 6IN D 1
14 CY-129418 -12530 LABEL, MARK 2
15 CY-129900 -12530 COVER ASSY 1
16 CY-119808-12540 VALVE, UNLOADER 1
17 CY-129062-12560 ELEMENT 1
18 CY-119005-12571 ELEMENT, INNER 1
19 CY-1A8275- 05530 PLATE,SHUTTER,84T 1
20 CY-1A8240-05810 COVER, BELT L 1
21 CY-1A8240-05820 COVER, BELT R 1
22 CY-1A7180 - 06201 PIPE A,INTAKE 1
23 CY-1A8260-06210 HOSE ASSY, INTAKE B 1
24 CY-129410-03990 CLAMP 22 1
25 CY-1A8260-06220 HOSE, INTAKE B 1
26 CY-1A8260-06230 JOINT, BREATHER 1
27 CY-1A8260-06240 SPRING, 1
28 CY-1A8240-15460 BRACKET, CLAMP 1
29 CY-198220-37900 PIN 8X24 1
Ref.
Part Number Description Qty
30 CY-121750-49150 PIPE, C. WATER 1
31 CY-175022-49750 CLIP 37, HOSE 2
32 CY-194440-51620 CLAMP, WIRE HARNESS 1
33 CY-194680-51670 BAND 2
34 CY-194680-51670 BAND 1
35 CY-1A7601-53920 URETHANE,SIDE LAMP 1
36 CY-114270-59010 CLIP, HOSE 2
37 CY-114270-59010 CLIP, HOSE 4
38 CY-114270-59010 CLIP, HOSE 2
39 CY-23000-019000 CLAMP 19 1
40 CY-23000-019000 CLAMP 19 1
41 CY-23000-035000 CLAMP 35 2
42 CY-23000-035000 CLAMP 35 2
43 CY-23000-070000 CLAMP 70 2
44 CY-Y23000080000 CLAMP 80 1
45 CY-23980-730200 HOSE 7.3X200,BRAIDED 1
46 CY-23980-730400 FUEL PIPE 7.3X400 2
47 CY-23980-730600 FUEL PIPE 7.3X600 1
48 CY-26106-060202 BOLT M 6X 20 PLATED 4
49 CY-26106-080122 BOLT M 8X 12 PLATED 2
50 CY-26106-080122 BOLT M 8X 12 PLATED 3
51 CY-26106-080162 BOLT M 8X 16 PLATED 2
52 CY-26106-080162 BOLT M 8X 16 PLATED 3
53 CY-26106-080162 BOLT M 8X 16 PLATED 1
54 CY-26106-080302 BOLT M 8X 30 PLATED 2
55 CY-26106-100202 BOLT M10X 20 PLATED 1
56 CY-198071- 61890 NUT 6,SPEED 1
57 CY-26106-060202 BOLT M 6X 20 PLATED 1
