Fig 9. Fuel Tank
Ref.
Part Number Description Qty
1 CY-1A8250-04100 TANK, FUEL ASSY 1
2 CY-1A8250-04110 TANK, FUEL 1
3 CY-1A8160 -04130 CAP, FUEL TANK 1
4 CY-1A7180 -04180 SCREW, 5 X 14 5
5 CY-1A8275-56600 FUEL SENDER ASSY 1
6 CY-194420-56620 GASKET 1
7 CY-1A8250-04210 BAND, TANK REAR L 1
8 CY-1A8250-04220 BAND, TANK REAR R 1
9 CY-1A8250-04230 BUFFER, BAND 2
10 CY-198153-04670 CLAMP 2
11 CY-22157-080000 WASHER 8 2
12 CY-26346-080002 U-NUT M 8 4
13 CY-26346-080002 U-NUT M 8 2
