Now you will build the arch connectors for the long side of the canopy frame.
Insert two #5 poles into the #8 corner connectors and join in the middle with the #6
connector. Tighten the screws (#20). Repeat to build the other side arch. Do a final
tighten of all screws.
5
5
8
6
11
21
Push poles
all the way into
connectors
6
Center your mattress (not included - must be a full, 8-10" thick mattress) on the
slats (#22). Orient the canopy (#11) on the frame. The Velcro skirt will be at the
bottom and the "smile" zippers should be facing up. Wrap one of the top horizontal
end sleeves around the pole and secure it with the buckle provided to hold the canopy
weight, before zipping the sleeve over the pole. Repeat with the other side.
9
