Cubby Bed - Parts List

Parts List
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
23
17
18
19
20
21
22
16
24
Top End Pole (x2)
Vertical Corner Pole (x4)
Bottom Length Pole (x4)
Bottom End Pole (x2)
Top Arch Pole (x4)
Arch Connector (x2)
Straight Connector (x2)
Top Corner Connector (x4)
Bottom Corner L Bracket (x2)
Bottom Corner R Bracket (x2)
Canopy
Safety Sheet
Canopy Hole Cover
Screws - Extras Included
Canopy Eyes (x4)
Canopy Feet (x4)
Hex Key
Locks
Safety Clasps ("S-clips")
Velcro Straps
Mattress - Sold Separately
Slats - Not Shown
1
2 34 567 8 9 10 11 12
15 16
13 19 17
23
1820
Canopy Ears (x4)
14
24
Canopy Straps
(Included with canopy)
5
