Cudy POE300 User Manual

5
LED and Interface Explanation
Data/PoE
PoE injector got 100-240V power input.
Mode A
1/2 (-) 3/6 (+) Power input
Mode B
4/5 (+) 7/8 (-) Power output
AC Socket
Connect with AC cable
PoE/DATA
Connect to the camera with UTP cable CAT5E or CAT6 supply power.
DATA/IN
Connect to the Ethernet device with CAT5E or CAT6 UTP cable to
transmit data.
Specifications
Model
POE300
Output voltage
53V DC
PoE power
Max. 30W & 60W
Standard
802.3af/at/bt
Pin Polarity
1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-)
Data rates
10/100/1000 Mbps
Input power
requirements
AC input voltage: 100 to 240 V AC
AC input current: 0.5A 100-240 V AC
AC frequency: 50-60 Hz
Dimensions
168×73.5×44 mm
Indicators
System indicator: AC power
User indicator: Channel power
Connectors
Shielded RJ-45, EIA 568A and 568B
Protection
Overcurrent protection
Overload protection
Overvoltage protection
Anti-interference protection
Environmental
conditions
Operating temperature: 0 to 40 °C
Operating humidity: max. 85%
Storage temperature: -40 to 60 °C

Cudy POE300 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Power over Ethernet (PoE)	Yes
Product color	Black
LED indicators	Power
Pin assignment & polarity	1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-)
RJ-45 input ports	1
Ethernet LAN (RJ-45) ports	2
Output power	60 W
Input current	0.5 A
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Power over Ethernet (PoE) voltage	50 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 80 %
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	60 mm
Width	145 mm
Height	40 mm
